Ford 4500
| | 1965 - 1975 |
| Industrial tractor |
|
| Production |
| Manufacturer | Ford
|
| Industrial tractor |
| Ford 4500 Power |
| Engine (gross) | 58.2 hp
43.4 kW
|
| Engine (net) | 55.3 hp
41.2 kW
|
| Gasoline PTO (claimed) | 45.4 hp
33.9 kW
|
| Diesel PTO (claimed) | 45.6 hp
34.0 kW
|
| Mechanical |
| Two-wheel drive |
| Steering | power assist
|
| Mechanical wet disc brakes |
| Open operator station. Four-post ROPS available. |
| Capacity |
| Fuel | 16 gal
60.6 L
|
| Hydraulic system | 6.5 gal (hitch)
24.6 L
|
| | 14 gal (loader)
53.0 L
|
| | 8 gal (backhoe)
30.3 L
|
| Hydraulics |
| Capacity | 6.5 gal (hitch)
24.6 L
|
| | 14 gal (loader)
53.0 L
|
| | 8 gal (backhoe)
30.3 L
|
| Valves | 0 to 2
|
| Pump flow | 4.5 gpm (hitch)
17.0 lpm
|
| | 21.3 gpm (loader)
80.6 lpm
|
| Total flow | 26.6 gpm
100.7 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 2000 lbs
907 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| | independent OptOptional
|
| Rear PTO Type | 540
|
| 4500 Serial Numbers |
| Location: | Serial number stamped on the right side of the Ford 4500 clutch housing, behind the starter. Additional plate inside the Ford 4500 hood panel, on the right side.
|
| Electrical |
| Ground | negative
|
| Charging system | generator
|
| Charging amps | 22
|
| Battery volts | 12
|
| Gasoline Battery AH | 80
|
| Diesel Battery AH | 128
|
| Questions |
I am having a difficult time figuring out the exact model of the backhoe accessory. I see the serial number is CBxxxxx with a 19-551 also printed on the ID plate.
That is a 755 series unit. 19-551 is the model number of the backhoe.
|
| Email: Peter@TractorData.com |
| References |
 |
| 3400 3500 4400 4500 Industrial Operator's Manual (SE 3226) published in 1968 |
| Industrial Tractors and Equipment published in 1965, by Ford |
| New-Size Ford Tractors Loaders-Backhoes published in 1965 |
| Tractors For Industrial Use published in 1967, by Ford |
| Industrial Tractors & Equipment Specifications 1969 published by Ford |
| Buyer's Guide '73 published in 1973, by Ford |
| Buyer's Guide '74 published in 1974, by Ford |
| Industrial Sales Handbook published in 1966, by Ford |
