Ford 3400
| | 1965 - 1975 |
| Industrial tractor |
|
| Production |
| Manufacturer | Ford
|
| Industrial tractor |
| Built in Highland Park, Michigan, USA |
| Ford 3400 Power |
| Engine (net) | 46.7 hp
34.8 kW
|
| Gas PTO (claimed) | 39.2 hp
29.2 kW
|
| Diesel PTO (claimed) | 39.5 hp
29.5 kW
|
| Mechanical |
| Two-wheel drive |
| Final drives | bevel gear
|
| Differential lock | mechanical rear OptOptional
|
| Steering | manual
|
| Steering | power OptOptional
|
| Mechanical expanding shoe brakes |
| Open operator station. Two- or four-post ROPS optional |
| Capacity |
| Fuel | 13 gal
49.2 L
|
| Hydraulic system | 6.15 gal
23.3 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 6.15 gal
23.3 L
|
| Pressure | 2500 psi*Tractor hydraulics
172.4 bar
|
| | 1800 psi*730 Loader pump
124.1 bar
|
| Valves | 0 to 2
|
| Pump flow | 4.8 gpm*Tractor hydraulics
18.2 lpm
|
| | 15.8 gpm*730 Loader hydraulic pump
59.8 lpm
|
| Total flow | 4.8 gpm
18.2 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at 24"/610mm) | 1700 lbs
771 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission OptOptional
|
| | live *Optional with 8-speed transmission.
|
| | independent *Optional with Select-O-Speed transmission.
|
| Rear PTO Type | 540
|
| 3400 Serial Numbers |
| Location: | Serial number plate inside the Ford 3400 hood panel, on the right side.
|
| Electrical |
| Ground | negative
|
| Charging system | generator
|
| Charging amps | 22
|
| Battery volts | 12
|
| Gasoline Battery AH | 80
|
| Diesel Battery AH | 128
|
| References |
 |
| 3400 3500 4400 4500 Industrial Operator's Manual (SE 3226) published in 1968 |
| 3400 Tractor published in 1966, by Ford |
| Industrial Tractors and Equipment published in 1965, by Ford |
| New-Size Ford Tractors Loaders-Backhoes published in 1965 |
| Tractors For Industrial Use published in 1967, by Ford |
| Industrial Tractors - Equipment published in 1968, by Ford |
| Industrial Tractors & Equipment Specifications 1969 published by Ford |
| Buyer's Guide '73 published in 1973, by Ford |
| Buyer's Guide '74 published in 1974, by Ford |
| Industrial Sales Handbook published in 1966, by Ford |
