Ford 545A
|
|
| Production | |
| Manufacturer | Ford |
| Industrial tractor | |
| Ford 545A Engine | |
| Ford 3.3L 3-cyl diesel | |
 Engine details ... |
| Ford 545A Transmissions | |
| 8-speed | |
| 6-speed | |
| 4-speed | |
 Transmission details ... |
| Ford 545A Power | |
| Engine (gross) | 63 hp 47.0 kW |
| Engine | 60 hp 44.7 kW |
| PTO (claimed) | 52 hp 38.8 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | standard |
| Steering | hydrostatic power |
| Differential mechanical wet disc brakes | |
| Two-post ROPS. Four-post ROPS with canopy optional. High-clearance canopy for backhoe. | |
| Photos | |
 | |
 Ford 545A photos... | |
| Capacity | |
| Fuel | 16 gal 60.6 L |
| Hydraulic system | 8.5 gal 32.2 L |
| 12 gal (independent PTO) 45.4 L | |
| 9.1 gal (loader) 34.4 L | |
| 22 gal (backhoe) 83.3 L | |
| Steering | 4 qts 3.8 L |
| Hydraulics | |
| Type | open center |
| Capacity | 8.5 gal 32.2 L |
| 12 gal (independent PTO) 45.4 L | |
| 9.1 gal (loader) 34.4 L | |
| 22 gal (backhoe) 83.3 L | |
| Pressure | 2500 psi (tractor) 172.4 bar |
| Rear valves | 1 (optional) |
| Total flow | 5.6 gpm 21.2 lpm |
| 8.5 gpm (independent PTO) 32.2 lpm | |
| 28.5 gpm (loader/backhoe) 107.9 lpm | |
| Steering flow | 5.9 gpm 22.3 lpm |
| Steering cap. | 4 qts 3.8 L |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 3,080 lbs 1397 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent (with 6 or 8 speed) |
| transmission (6 speed) | |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 81 inches 205 cm |
| Weight | 5196 to 12960 pounds |
| Front tire | 7.50-16 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| Ford 545A attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Charging amps | 32 |
| 51 (optional) | |
| Battery CCA | 750 |
| Battery volts | 12 |
| Battery AH | 128 |
| References | |
 | |
| Industrial Buyer's Guide 1984-1985 published by Ford | |
| 1986 Industrial Buyer's Guide published by Ford |
