J.I. Case 380CK
| | 1971 - 1980 |
| Industrial tractor |
|
| Production |
| Manufacturer | J.I. Case
|
| Type | Industrial tractor
|
| The Case 380 is based on the David Brown model 885. |
| J.I. Case 380CK Power |
| Engine (net) | 48 hp
35.8 kW
|
| Drawbar (claimed) | 31 hp
23.1 kW
|
| PTO (claimed) | 36 hp
26.8 kW
|
| Mechanical |
| Chassis | 4x2 2WD
|
| Differential lock | foot operated
|
| Steering | hydrostatic power
|
| Brakes | drum
|
| Capacity |
| Fuel | 12.6 gal
47.7 L
|
| Hydraulic system | 4.75 gal
18.0 L
|
| Steering | 9 qts
8.5 L
|
| Hydraulics |
| Type | gear pump
|
| Capacity | 4.75 gal
18.0 L
|
| Pressure | 1750 psi (loader)
120.7 bar
|
| | 2000 psi (hitch)
137.9 bar
|
| Pump flow | 17.5 gpm (loader)
66.2 lpm
|
| | 7.3 gpm (hitch)
27.6 lpm
|
| Steering cap. | 9 qts
8.5 L
|
| Tractor hitch |
| Rear Type | 2/1
|
| Rear lift (at ends) | 1,750 lbs
793 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear RPM | 540 (1.375)
|
| Engine RPM | 540@1800
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 26
|
| Battery volts | 12
|
| Battery AH | 95
|
| Page information |
| Contact: Peter Easterlund |
| Updated on January 20, 2015 |
| Copyright 2021 TractorData LLC |
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
J.I. Case 380CK photos...
