International Harvester 3616
|
|
| Production | |
| Manufacturer | International Harvester |
| Industrial tractor | |
| International Harvester 3616 Engines | |
| International Harvester 3.9L 6-cyl diesel | |
| International Harvester 3.6L 6-cyl gasoline | |
 Engine details ... |
| International Harvester 3616 Transmissions | |
| 5-speed unsynchronized gear | |
| 4-speed | |
| 5-speed unsynchronized shuttle | |
| hydrostatic | |
 Transmission details ... |
| International Harvester 3616 Power | |
| Engine | 66 hp 49.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Steering | hydrostatic power |
| Differential mechanical disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the International Harvester 3616 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 20 gal 75.7 L |
| Hydraulic system | 20 gal 75.7 L |
| Hydraulics | |
| Capacity | 20 gal 75.7 L |
| Valves | 2 |
| Pump flow | 19 gpm (front pump) 71.9 lpm |
| 22 gpm (optiona front pump) 83.3 lpm | |
| 10 gpm (transmission pump) 37.9 lpm | |
| Total flow | 36 gpm (total) 136.3 lpm |
| 39 gpmOptOptional 147.6 lpm | |
| Steering flow | 7 gpm 26.5 lpm |
| Steering press. | 2200 psi 151.7 bar |
| Tractor hitch | |
| Rear Type | II OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 84.9 inches 215 cm |
| Weight | 7950 lbs 3606 kg |
| Front tire | 7.50-18 |
| Rear tire | 14.9-28 |
 Full dimensions and tires ... | |
| International Harvester 3616 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | Delco-Remy generator |
| Charging amps | 20 |
| Gas Batteries | 1 |
| Diesel Batteries | 2 |
| Gas Battery volts | 12 |
| Diesel Battery volts | 6 |
| References | |
 | |
| Buyer's Guide 1967 published by International Harvester | |
| Operator's Manual 3616 Loader Tractor published in 1974, by International Harvester |
