Ford 1881
|
|
| Production | |
| Manufacturer | Ford |
| Industrial tractor | |
| Variants | |
| 1811 | Select-O-Speed, no PTO or hydraulics |
| 1821 | Four-speed, no PTO or hydraulics |
| 1841 | Four-speed with PTO and hydraulics |
| 1871 | Select-O-Speed with PTO and hydraulics |
| 1881 | Select-O-Speed with multi-speed PTO and hydraulics |
| Ford 1881 Engine | |
| Ford 2.8L 4-cyl gasoline | |
 Engine details ... |
| Ford 1881 Transmission | |
| 10-speed power shift | |
 Transmission details ... |
| Ford 1881 Power |
| Mechanical | |
| Two-wheel drive | |
| Steering | 12x28 |
| Differential mechanical shoe brakes | |
| Open operator station | |
| Photos | |
| No photos of the Ford 1881 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 17 gal 64.3 L |
| Hydraulic system | 2 gal 7.6 L |
| Rear axle | 11.5 qts 10.9 L |
| Hydraulics | |
| Capacity | 2 gal 7.6 L |
| Pressure | 2000 psi 137.9 bar |
| Total flow | 4 gpm 15.1 lpm |
| Steering flow | 8 gpm 30.3 lpm |
| Steering press. | 1500 psi 103.4 bar |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000/ground |
| Dimensions & Tires | |
| Wheelbase | 81.5 inches 207 cm |
| Weight | 3,800 lbs 1723 kg |
| Front tire | 7.50x16 |
| Rear tire | 12x28 |
 Full dimensions and tires ... | |
| Ford 1881 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | positive (6V) |
| negative (12V) | |
| Charging system | generator |
| Charging amps | 20 |
| Batteries | 1 (gas) |
| 2 (diesel) | |
| Battery volts | 6 |
| Battery AH | 80 |
| References | |
 | |
| Series 713 Backhoes published in 1959, by Ford | |
| Industrial Line published in 1958, by Ford | |
| Now! Shift to any speed on the Go! published in 1959, by Ford | |
 | |
| Operator's Manual Industrial Tractor (SE-6895-A) published in 1958 | |
| 1955-1960 Tractor Shop Manual (SE-8175) published in 1961 | |
| Service Manual Select-O-Speed Transmission (SE 6978) published in 1959 |
