Renault 701
| | 1984 - 1985 |
| Utility tractor | | Carraro built |
|
Series map:
601
701
44.2kw
51.5kw
| Production |
| Distributor | Renault
|
| Manufacturer | Carraro
|
| Utility tractor |
| Built in Italy |
| Renault 701 Power |
| Engine | 69 hp
51.5 kW
|
| PTO (claimed) | 59.3 hp
44.2 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Mechanical wet disc brakes |
| Four-post ROPS. |
| Photos |
| No photos of the Renault 701 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2611 psi
180.0 bar
|
| Pump flow | 7.9 gpm
29.9 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 3846 lbs
1744 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2014
|
| | 1000@2119
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 28
|
| Battery volts | 12
|
| Battery AH | 100
|
| References |
 |
| 701-4F Fruitiers published by Renault |
