Renault 601
| | 1982 - 1987 |
| Utility tractor | | Carraro built |
|
Series map:
501
601
701
36.8kw
44.2kw
51.5kw
| Production |
| Distributor | Renault
|
| Manufacturer | Carraro
|
| Utility tractor |
| Built in Italy |
| Variants |
| 601-2 | 2WD
|
| 601-4 | 4WD
|
| Renault 601 Power |
| Engine | 59.3 hp
44.2 kW
|
| PTO (claimed) | 55.9 hp
41.7 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Mechanical disc brakes |
| Four-post ROPS. |
| Photos |
| No photos of the Renault 601 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2611 psi
180.0 bar
|
| Pump flow | 7.4 gpm
28.0 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 5958 lbs
2702 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2014
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 28
|
| Battery volts | 12
|
| Battery AH | 100
|
| References |
 |
| 501-4 601-4 published in 1985, by Renault |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on March 10, 2026 |
