John Deere 2027R
2013 - 2016 2R Series Compact Utility tractor
Production Manufacturer John Deere
Compact Utility tractor Built in Augusta, Georgia, USA
John Deere 2027R Power Engine (gross) 26.5 hp19.8 kW
PTO (claimed) 20.5 hp15.3 kW
Mechanical Four-wheel drive Final drives spur gear
Differential lock mechanical rear
Power steering Wet disc brakes Two-post folding ROPS.
Photos No photos of the John Deere 2027R are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Hydraulics Type open center
Tractor hitch Rear Type I
Control position control
Rear lift (at ends) 1433 lbs650 kg
Rear lift (at 24"/610mm) 1150 lbs521 kg
Power Take-off (PTO) Rear PTO independent
Rear PTO Type 540 (1.375)
Mid PTO independent
Mid PTO Type 2100
2027R Serial Number Location Right side of tractor frame, above and behind the front axle.
Electrical Ground negative
Charging system alternator
Charging amps 40
Battery CCA 500
Battery volts 12
References Operator's Manual 2025R, 2027R and 2032R Compact Utility Tractors (OMVLU26876) published in 2015
