CaseIH Magnum 295
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| Original price | $510,717 (2026 Power Shift ) |
| $518,833 (2026 CVT ) | |
| CaseIH Magnum 295 Engine | |
| FPT 8.7L 6-cyl diesel | |
| Fuel tank | 179 gal (PS) 677.5 L |
| 163 gal (CVT) 617.0 L | |
| Exhaust fluid (DEF) | 26 gal 98.4 L |
 Engine details ... | |
| CaseIH Magnum 295 Transmissions | |
| 19-speed full power shift | |
| continuously-variable transmission | |
 Transmission details ... |
| CaseIH Magnum 295 Power | |
| Engine (gross) | 295 hp 220.0 kW |
| Engine (max) | 325 hp 242.4 kW |
| Engine (boost) | 351 hp 261.7 kW |
| PTO (claimed) | 248 hp 184.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electronic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Magnum 295 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | pressure flow compensating |
| Valves | 5 or 6 |
| Pump flow | 59 gpm 223.3 lpm |
| 86 gpmOptOptional 325.5 lpm | |
| Tractor hitch | |
| Rear Type | III/IIIN |
| IV/IVN ((Optional) | |
| Rear lift | 15900 lbs 7212 kg |
| 17500 lbsOptOptional 7938 kg | |
| Front lift | 9426 lbs 4275 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.75) |
| 540/1000 (1.375)OptOptional | |
| Front PTO | independent |
| Front PTO Type | 1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 120 inches (PS) 304 cm |
| 122 inches (CVT) 309 cm | |
| Weight | 28600 lbs 12972 kg |
| Front tire | 420/85R34 |
| Rear tire | 480/80R50 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 240 |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| Magnum published in 2025, by CaseIH |
