Massey Ferguson 5M.105
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Utility tractor | |
| Massey Ferguson 5M.105 Engine | |
| AGCO Power 4.4L 4-cyl diesel | |
| Fuel tank | 52.3 gal 198.0 L |
| Exhaust fluid (DEF) | 4.8 gal 18.2 L |
 Engine details ... | |
| Massey Ferguson 5M.105 Transmission | |
| 16-speed four-speed power shift | |
 Transmission details ... |
| Massey Ferguson 5M.105 Power | |
| Engine | 100 hp 74.6 kW |
| Engine (max) | 105 hp 78.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic |
| pneumatic OptOptional | |
| Cab standard with available air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 5M.105 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2901 psi 200.0 bar |
| Valves | 2 or 3 |
| Pump flow | 15.3 gpm 57.9 lpm |
| 26.4 gpmOptOptional 99.9 lpm | |
| Steering flow | 8.5 gpm 32.2 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 9480 lbs 4300 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2000 |
| 540E@1550 | |
| 1000@2000 | |
| Dimensions & Tires | |
| Wheelbase | 95.7 inches 243 cm |
| Weight | 9921 lbs 4500 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MF 5M - Affordable Efficiency published in 2024, by Massey Ferguson |
