Massey Ferguson 5M.95
| | 2025 - |
| 5M Series | | Utility tractor |
|
Series map:
5M.95
5M.105
90.0hp
100.0hp
| Production |
| Manufacturer | Massey Ferguson (a part of AGCO)
|
| Utility tractor |
| Massey Ferguson 5M.95 Power |
| Engine | 90 hp
67.1 kW
|
| Engine (max) | 95 hp
70.8 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | electro-hydraulic
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic
|
| | pneumatic OptOptional
|
| Cab standard with available air-conditioning. |
| Photos |
| No photos of the Massey Ferguson 5M.95 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pressure | 2901 psi
200.0 bar
|
| Valves | 2 or 3
|
| Pump flow | 15.3 gpm
57.9 lpm
|
| | 26.4 gpmOptOptional
99.9 lpm
|
| Steering flow | 8.5 gpm
32.2 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 9480 lbs
4300 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@2000
|
| | 540E@1550
|
| | 1000@2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| MF 5M - Affordable Efficiency published in 2024, by Massey Ferguson |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on November 28, 2025 |
