Tractors > Valtra > T235

Valtra T235



No photo available
2022 -
T 5 Series
Row-Crop tractor
Series map:
T215
T235
T255
-0.7kw
-0.7kw
-0.7kw
Production
ManufacturerValtra (a part of AGCO)
Row-Crop tractor
Built in Suolahti, Finland
Valtra T235 Engine
AGCO Power 7.4L 6-cyl diesel
Fuel tank100.4 gal
380.0 L
 66 gal (steel tank)
249.8 L
Exhaust fluid (DEF)18.5 gal
70.0 L
Engine details ...
Valtra T235 Transmissions
30-speed five-speed power shift
continuously-variable transmission
Transmission details ...
Valtra T235 Power
Engine (max)235 hp
175.2 kW
Engine (boost)250 hp
186.4 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Valtra T235 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center load-sensing OptOptional
Rear valves5 OptOptional
Front valves4 OptOptional
Pump flow19.3 gpm (open center)
73.1 lpm
 23.8 gpm (open center)OptOptional
90.1 lpm
 30.4 gpm (closed center)
115.1 lpm
 42.3 gpm (closed center)OptOptional
160.1 lpm
 52.8 gpm (closed center)OptOptional
199.8 lpm
Tractor hitch
Rear TypeIII
Rear lift18209 lbs
8259 kg
 21356 lbsOptOptional
9687 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540E@1522
 540@1890
 1000@1897
Front PTOindependent OptOptional
Front PTO Type1000
Engine RPM1000@2000
Dimensions & Tires
Wheelbase117.9 inches
299 cm
Weight16904 lbs
7667 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
T235 references literature
T Series published in 2021, by Valtra
