Tractors > Valtra > T174

Valtra T174



No photo available
2014 - 2021
T 4 Series
Row-Crop tractor
Series map:
T154
T174
T194
-0.7kw
-0.7kw
-0.7kw
Production
ManufacturerValtra (a part of AGCO)
Row-Crop tractor
Built in Suolahti, Finland
Valtra T174 Engine
AGCO Power 7.4L 6-cyl diesel
Fuel tank100.4 gal
380.0 L
Exhaust fluid (DEF)18.5 gal
70.0 L
Engine details ...
Valtra T174 Transmissions
30-speed five-speed power shift
continuously-variable transmission
Transmission details ...
Valtra T174 Power
Engine (max)175 hp
130.5 kW
Engine (boost)190 hp
141.7 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Valtra T174 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center load-sensing OptOptional
Rear valves5 OptOptional
Front valves4 OptOptional
Pump flow19.2 gpm (open center)
72.7 lpm
 23.6 gpm (open center)OptOptional
89.3 lpm
 30.4 gpm (CCLS)
115.1 lpm
 42.3 gpm (CCLS)OptOptional
160.1 lpm
 52.8 gpm (CCLS)OptOptional
199.8 lpm
Tractor hitch
Rear TypeIII
Rear lift17534 lbs
7953 kg
 20232 lbsOptOptional
9177 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Front PTOindependent OptOptional
Front PTO Type1000
Dimensions & Tires
Wheelbase117.9 inches
299 cm
Weight29762 lbs
13500 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
T174 references literature
T Series published in 2019, by Valtra
