SAME Dorado 90
|
|
| Production | |
| Manufacturer | SAME |
| Utility tractor | |
| SAME Dorado 90 Engine | |
| SDF 4.0L 4-cyl diesel | |
| Fuel tank | 26.4 gal 99.9 L |
| Classic Fuel tank | 19.8 gal 74.9 L |
 Engine details ... | |
| SAME Dorado 90 Transmissions | |
| 10-speed partially synchronized | |
| 30-speed partially synchronized | |
| 45-speed three-speed power shift | |
 Transmission details ... |
| SAME Dorado 90 Power | |
| Engine (gross) | 85 hp 63.4 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic |
| Two-post ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the SAME Dorado 90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 14.3 gpm 54.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 6614 lbs 3000 kg |
| 7937 lbsOptOptional 3600 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375) | |
| Front PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 86 inches 218 cm |
| 4WD Wheelbase | 87.8 inches 223 cm |
| Weight | 6945 to 7518 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Dorado3 70-80-90-100 published in 2010, by SAME | |
| Dorado3 60-80-90-100 published in 2010, by SAME | |
| Dorado3 Classic 60-70-80-90 published in 2011, by SAME |
