Kubota ME9000
| | 2003 - 2010 |
| ME Series | | Utility tractor |
|
Series map:
ME8200
ME9000
64.7kw
69.9kw
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Variants |
| ME9000DTH-L | low-profile
|
| Kubota ME9000 Power |
| Engine (gross) | 93.8 hp
69.9 kW
|
| PTO (claimed) | 81.2 hp
60.6 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic
|
| Two-post sliding ROPS. Cab optional with air-conditioning. |
| Photos |
| No photos of the Kubota ME9000 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves | 2 or 3
|
| Pump flow | 17 gpm
64.3 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift (at ends) | 8818 lbs
3999 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| ROPS Charging amps | 45
|
| Cab Charging amps | 60
|
| Battery volts | 12
|
| References |
 |
| ME Series published in 2003, by Kubota |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on July 12, 2025 |
©2000-2025 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
