Kubota ME5700
| | 2003 - 2010 |
| ME Series | | Utility tractor |
|
Series map:
ME5700
ME8200
46.6kw
64.7kw
| Production |
| Manufacturer | Kubota
|
| Utility tractor |
| Kubota ME5700 Power |
| Engine (gross) | 62.5 hp
46.6 kW
|
| PTO (claimed) | 52.8 hp
39.4 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Mechanical wet disc brakes |
| Trailer brakes | mechanical OptOptional
|
| Two-post fixed ROPS. Cab optional with air-conditioning. Two-post folding mid-mount ROPS on narrow model. |
| Photos |
| No photos of the Kubota ME5700 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves | 1 or 2
|
| Pump flow | 11 gpm
41.6 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position and draft control
|
| Rear lift (at ends) | 4189 lbs
1900 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| ROPS Charging amps | 40
|
| Cab Charging amps | 60
|
| Battery volts | 12
|
| References |
 |
| ME Series published in 2003, by Kubota |
