Tractors > Yanmar > SA426

Yanmar SA426



No photo available
2025 -
SA Series
Compact Utility tractor
Series map:
SA326
SA426
17.4kw
17.4kw
Production
ManufacturerYanmar
Compact Utility tractor
Built in Torbali, Turkey
Yanmar SA426 Engine
Yanmar 1.1L 3-cyl diesel
Engine details ...
Yanmar SA426 Transmission
hydrostatic
Transmission details ...
Yanmar SA426 Power
Engine (gross)23.4 hp
17.4 kW
PTO (claimed)19 hp
14.2 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional with heat.
Photos
No photos of the Yanmar SA426 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel6.1 gal
23.1 L
Front axle3.2 qts
3.0 L
Hydraulics
Typeopen center
Pressure2422 psi
167.0 bar
Mid valves2
Pump flow4 gpm
15.1 lpm
Steering flow3.5 gpm
13.2 lpm
Tractor hitch
Rear TypeI (Limited)
Rear lift (at 24"/610mm)1208 lbs
547 kg
Power Take-off (PTO)
Rear PTOindependent
Clutch540:3120
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO TypeSAE 16/32
Engine RPM2000@3111
Dimensions & Tires
Wheelbase63 inches
160 cm
Weight1874 to 2377 pounds
Full dimensions and tires ...
SA426 Serial Numbers
Location:Serial number plate on the front right of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
SA426 references literature
Operation Manual SA Compact Tractor (0A041-EN0590) published in 2024
