Yanmar SA326
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Built in Torbali, Turkey | |
| Yanmar SA326 Engine | |
| Yanmar 1.1L 3-cyl diesel | |
 Engine details ... |
| Yanmar SA326 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Yanmar SA326 Power | |
| Engine (gross) | 23.4 hp 17.4 kW |
| PTO (claimed) | 19 hp 14.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with heat. |
| Photos | |
| No photos of the Yanmar SA326 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 6.1 gal 23.1 L |
| Front axle | 3.2 qts 3.0 L |
| Hydraulics | |
| Type | open center |
| Pressure | 2422 psi 167.0 bar |
| Mid valves | 2 |
| Pump flow | 4 gpm 15.1 lpm |
| Steering flow | 3.5 gpm 13.2 lpm |
| Tractor hitch | |
| Rear Type | I (Limited) |
| Rear lift (at 24"/610mm) | 1208 lbs 547 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | 540:3120 |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent |
| Mid PTO Type | SAE 16/32 |
| Engine RPM | 2000@3111 |
| Dimensions & Tires | |
| Wheelbase | 63 inches 160 cm |
| Weight | 1759 to 2262 pounds |
 Full dimensions and tires ... | |
| SA326 Serial Numbers | |
| Location: | Serial number plate on the front right of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Operation Manual SA Compact Tractor (0A041-EN0590) published in 2024 |
