Tractors > Yanmar > YM347

Yanmar YM347



Yanmar YM347 tractor photo
2023 -
YM3 Series
Compact Utility tractor
Series map:
YM347
YM359
35.0kw
43.9kw
Production
ManufacturerYanmar
Compact Utility tractor
Yanmar YM347 Engine
Yanmar 2.2L 4-cyl diesel
Engine details ...
Yanmar YM347 Transmission
12-speed synchronized
Transmission details ...
Yanmar YM347 Power
Engine (gross)47 hp
35.0 kW
PTO (claimed)35.5 hp
26.5 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post folding mid-mount ROPS.
Photos
No photos of the Yanmar YM347 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel12.7 gal
48.1 L
Hydraulic system7.7 gal
29.1 L
Hydraulics
Typeopen center
Capacity7.7 gal
29.1 L
Pressure2422 psi
167.0 bar
Valves2
Pump flow4.5 gpm
17.0 lpm
Total flow10.2 gpm
38.6 lpm
Steering flow5.7 gpm
21.6 lpm
Power Take-off (PTO)
Clutch540:2430
 750:2430
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase77.6 inches
197 cm
Weight4597 lbs
2085 kg
Full dimensions and tires ...
Electrical
Charging systemalternator
Charging amps55
Battery volts12
Battery AH70
References
YM347 references literature
YM347A/YM359A Compact Tractor published in 2023, by Yanmar
