John Deere 60 Orchard
1952 - 1957 Orchard/Vineyard tractor
Series map:
60 Orchard
41.6hp*
*Estimated engine power for comparison only.
Production Manufacturer John Deere
Orchard/Vineyard tractor Built in Waterloo, Iowa, USA Total built 872
John Deere 60 Orchard Power Drawbar (claimed) 36.94 hp (gas)27.5 kW
30.09 hp (all-fuel)22.4 kW
Belt (claimed) 41.57 hp (gas)31.0 kW
33.26 hp (all-fuel)24.8 kW
Plows 3 * 14-inch
Mechanical Two-wheel drive Manual steering Mechanical drum brakes Open operator station.
Photos No photos of the John Deere 60 Orchard are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Capacity Fuel 20 gal75.7 L
Aux. fuel 1 gal3.8 L
Hydraulic system 1.5 gal5.7 L
Hydraulics Type open center
Capacity 1.5 gal5.7 L
Valves 1
Pump flow 8.9 gpm33.7 lpm
Power Take-off (PTO) Rear PTO transmission
independent Opt Optional Clutch dry disc
Rear PTO Type 540 (1.375)
Belt Pulley Diameter 12.8 inches32 cm
Width 7.375 inches18 cm
RPM 975
Speed 3270 ft/min996.70 meters/min
Electrical Ground positive
Charging system generator
Batteries 2
Battery volts 6
References The New Model 60 Orchard Tractor published in 1953, by John Deere Operator's Manual 60 Standard-Orchard Tractors (OM-R2029) published in 1954
