Fiat 312R
|
|
| Production | |
| Manufacturer | Fiat |
| Utility tractor | |
| Built in Modena, Italy | |
| Variants | |
| 311C | crawler |
| Fiat 312R Engine | |
| Fiat 1.9L 4-cyl diesel | |
| Fuel tank | 10.3 gal 39.0 L |
 Engine details ... | |
| Fiat 312R Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Fiat 312R Power | |
| Engine | 30 hp 22.4 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Fiat 312R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 1764 lbs 800 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2160 |
| Dimensions & Tires | |
| Wheelbase | 69.9 inches 177 cm |
| Weight | 3131 lbs 1420 kg |
| Front tire | 5.50-16 |
| Rear tire | 11.2/10-28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| 312R published in 1961, by Fiat |
