Massey Ferguson 6713S


Massey Ferguson 6713S tractor photo
2017 - 2021
6700S Series
Utility tractor
Series map:
6712S
6713S
6714S
110.0hp
115.0hp
130.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Utility tractor
Variants
MT465Esimilar Challenger model
Massey Ferguson 6713S Engine
AGCO Power 4.9L 4-cyl diesel
Fuel tank67 gal
253.6 L
Exhaust fluid (DEF)7.9 gal
29.9 L
Engine details ...
Massey Ferguson 6713S Transmissions
16-speed four-speed power shift
24-speed six-speed power shift
continuously variable transmission (CVT)
Transmission details ...
Massey Ferguson 6713S Power
Engine115 hp
85.8 kW
PTO (claimed)110 hp
82.0 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakespneumatic OptOptional
 hydraulic OptOptional
Cab standard with air-conditioning. Available cab suspension.
Photos
No photos of the Massey Ferguson 6713S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center OptOptional
Pressure2900 psi
200.0 bar
Rear valves5 OptOptional
Front valves2 OptOptional
Pump flow26.4 gpm (open)
99.9 lpm
 29.1 gpm (closed)
110.1 lpm
 50 gpmOptOptional
189.3 lpm
Tractor hitch
Rear TypeIII
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
Engine RPM540E@1530
 540@1980
 1000E@1570
 1000@2030
Front PTOindependent OptOptional
Front PTO Type1000
Engine RPM1000@1920
Dimensions & Tires
Wheelbase105.1 inches
266 cm
Weight15432 lbs
6999 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
6713S references literature
MF 6700 S published in 2018, by Massey Ferguson
MF 6700 S published in 2019, by Massey Ferguson
