Massey Ferguson 6S.135

Massey Ferguson 6S.135 tractor photo
2022 -
6S Series
Row-Crop tractor
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
Massey Ferguson 6S.135 Engine
AGCO Power 4.9L 4-cyl diesel
Fuel tank74 gal
280.1 L
Exhaust fluid (DEF)9.3 gal
35.2 L
Engine details ...
Massey Ferguson 6S.135 Transmissions
24-speed six-speed power shift
continuously-variable transmission
Transmission details ...
Massey Ferguson 6S.135 Power
Engine134.1 hp
100.0 kW
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
No photos of the Massey Ferguson 6S.135 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeopen center
 closed center OptOptional
Pressure2900 psi
200.0 bar
Rear valvesup to 5
Front valvesup to 2
Pump flow26.4 gpm (open)
99.9 lpm
 29.1 gpm (closed)
110.1 lpm
 39.6 gpm (closed optional)
149.9 lpm
 50.2 gpm (closed optional)
190.0 lpm
Tractor hitch
Rear TypeIII
Dyna-6 Rear lift15653 lbs
7100 kg
Dyna-VT Rear lift21164 lbs
9599 kg
Front HitchIII
Front lift7055 lbs
3200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/1000 (1.375)
Engine RPM540@1980
Front PTOindependent
Front RPM1000
Engine RPM1000@1920
Dimensions & Tires
Wheelbase105.1 inches
266 cm
Weight12787 to 15432 pounds
Front tire420/85R28
Rear tire520/85R38
Full dimensions and tires ...
6S.135 references literature
MF 6S - A New Era published in 2021, by Massey Ferguson
MF 6S Series published in 2022, by Massey Ferguson
