CaseIH Steiger 645 Quadtrac


CaseIH Steiger 645 Quadtrac tractor photo
2024 -
Steiger Quadtrac Series
Articulated Crawler tractor
Series map:
Steiger 595 Quadtrac
Steiger 645 Quadtrac
Steiger 715 Quadtrac
586.9hp
636.2hp
705.2hp
Production
ManufacturerCaseIH (a part of CNH)
Articulated Crawler tractor
CaseIH Steiger 645 Quadtrac Engine
FPT 12.9L 6-cyl diesel
Fuel tank470 gal
1779.0 L
Exhaust fluid (DEF)85 gal
321.7 L
Engine details ...
CaseIH Steiger 645 Quadtrac Power
Engine (gross)636.2 hp
474.4 kW
Engine (max)689.4 hp
514.1 kW
PTO (claimed)529.6 hp
394.9 kW
Mechanical
Drivearticulated crawler
Final drivesplanetary
Articulated power steering
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 645 Quadtrac are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpmOptOptional
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)22250 lbs
10092 kg
DrawbarCat 4
 Cat 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase154 inches
391 cm
Weight56800 lbs
25764 kg
Tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
 330 OptOptional
Batteries3
Battery CCA950
Battery volts12
References
Steiger 645 Quadtrac references literature
TAFS Connect Steiger published in 2024, by New Holland
