CaseIH Steiger 595 Quadtrac

CaseIH Steiger 595 Quadtrac tractor photo
2024 -
Steiger Quadtrac Series
Articulated Crawler tractor
Series map:
Steiger 555 Quadtrac
Steiger 595 Quadtrac
Steiger 645 Quadtrac
ManufacturerCaseIH (a part of CNH)
Articulated Crawler tractor
Built in Fargo, North Dakota, USA
CaseIH Steiger 595 Quadtrac Engine
FPT 12.9L 6-cyl diesel
Fuel tank470 gal
1779.0 L
Exhaust fluid (DEF)85 gal
321.7 L
Engine details ...
CaseIH Steiger 595 Quadtrac Power
Engine (gross)586.9 hp
437.7 kW
Engine (max)647 hp
482.5 kW
PTO (claimed)529.6 hp
394.9 kW
Drivearticulated crawler
Final drivesplanetary
Articulated power steering
Cab standard with air-conditioning.
No photos of the CaseIH Steiger 595 Quadtrac are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeclosed center
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpmOptOptional
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)22250 lbs
10092 kg
DrawbarCat 4
 Cat 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase154 inches
391 cm
Weight56800 lbs
25764 kg
Full dimensions and tracks ...
Charging systemalternator
Charging amps240
 330 OptOptional
Battery CCA950
Battery volts12
Steiger 595 Quadtrac references literature
TAFS Connect Steiger published in 2024, by New Holland
