CaseIH Magnum 220
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| Original price | $354,008 (2024 PS ) |
| $367,245 (2024 CVT ) | |
| CaseIH Magnum 220 Engine | |
| FPT 6.7L 6-cyl diesel | |
| Fuel tank | 160 gal 605.6 L |
| Exhaust fluid (DEF) | 17.5 gal 66.2 L |
 Engine details ... | |
| CaseIH Magnum 220 Transmissions | |
| 19-speed full power shift | |
| continuously-variable transmission | |
 Transmission details ... |
| CaseIH Magnum 220 Power | |
| Engine (gross) | 217 hp 161.8 kW |
| Engine (max) | 237 hp 176.7 kW |
| Engine (boost) | 260 hp 193.9 kW |
| PTO (claimed) | 185 hp 138.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electronic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Magnum 220 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | pressure flow compensating (PFC) |
| Valves | 3 to 5 |
| Pump flow | 39.6 gpm (PS) 149.9 lpm |
| 40.9 gpm (CVT) 154.8 lpm | |
| 61 gpm (PS TwinFlow) 230.9 lpm | |
| 65 gpm (CVT TwinFlow) 246.0 lpm | |
| SCV flow | 37.5 gpm (PS) 141.9 lpm |
| 40.9 gpm (CVT) 154.8 lpm | |
| 23.5 gpm*Remotes 1-3 when equipped with TwinFlow 88.9 lpm | |
| Tractor hitch | |
| Rear Type | III/IIIN |
| Control | electronic draft control |
| Rear lift | 13600 lbs 6168 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Engine RPM | 540@1950 |
| 1000@1892 | |
| Dimensions & Tires | |
| Wheelbase | 118.3 inches 300 cm |
| Weight | 20725 to 21350 pounds |
| Front tire | 380/85R34 |
| Rear tire | 480/80R46 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 240 |
| Battery volts | 12 |
| References | |
 | |
| AFS Connect Magnum published in 2021, by CaseIH | |
| Magnum published in 2025, by CaseIH |
