Tractors > CaseIH > Magnum 220

CaseIH Magnum 220 Transmission



CaseIH Magnum 220 tractor photo
2014 - 2027
Model year
Magnum Series
Row-Crop tractor
Series map:
Magnum 200
Magnum 220
Magnum 240
197.0hp
217.0hp
237.0hp
Transmission options
19-speed full power shift
continuously-variable transmission
Transmission
TransmissionPowerDrive
Typefull power shift
Gears19 forward and 4 reverse
Speeds
With 480/80R46 rear tires and 50kph transmission option.
Magnum 220 PowerDrive full power shift speeds
Transmission
TransmissionCVXDrive
Typecontinuously-variable transmission
Gearsinfinite forward and reverse
