John Deere 5120M


John Deere 5120M tractor photo
2022 -
5M Series
Utility tractor
Series map:
5105M
5120M
5130M
105.0hp
120.0hp
130.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Pune, India
Original price was $85,264 in 2023
John Deere 5120M Engine
John Deere 4.5L 4-cyl diesel
ROPS Fuel tank37.7 gal
142.7 L
Cab Fuel tank43.7 gal
165.4 L
Exhaust fluid (DEF)3.17 gal
12.0 L
Engine details ...
John Deere 5120M Transmissions
16-speed
16-speed 4-speed power shift
32-speed 8-speed power shift
Transmission details ...
John Deere 5120M Power
Engine120 hp
89.5 kW
PTO (claimed)105 hp
78.3 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic rear
Power steering
Two-post folding ROPS. Cab optional with air-conditioning
Photos
No photos of the John Deere 5120M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves2 or 3
Mid valves2 or 3
Pump flow24.7 gpm (PowReverser)
93.5 lpm
 25.6 gpm (PowrQuad/8)
96.9 lpm
SCV flow18.4 gpm (PowReverser)
69.6 lpm
 19.3 gpm (PowrQuad/8)
73.1 lpm
Tractor hitch
Rear TypeII/I
Controlposition control and lower-link draft sensing
Rear lift5150 lbs (PowrReverser)
2336 kg
 5950 lbs (PowrReverser optional)
2698 kg
 6970 lbs (PowrQuad/8)
3161 kg
 7860 lbs (PowrQuad/8 optional)
3565 kg
Front HitchII/I
Front lift4257 lbs
1930 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540 (1.375)
 540/1000 (1.375)OptOptional
Engine RPM540@2100
 540E@1645
 1000@2100
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight8765 to 9185 pounds
Front tire12.4R24
Rear tire18.4R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps90
Cab Charging amps120
 200 OptOptional
Battery volts12
References
5120M references literature
5M Tractors published in 2022, by John Deere
