Tractors > SAME > Diamond 270

SAME Diamond 270



SAME Diamond 270 tractor photo
2006 - 2012
Diamond Series
Row-Crop tractor
Series map:
936
Diamond 270
231.2kw
198.4kw
Production
ManufacturerSAME
Row-Crop tractor
SAME Diamond 270 Engine
Deutz 7.1L 6-cyl diesel
Fuel tank145.3 gal
550.0 L
Engine details ...
SAME Diamond 270 Transmission
40-speed four-speed power shift
Transmission details ...
SAME Diamond 270 Power
Engine (gross)266 hp
198.4 kW
Engine (max)271 hp
202.1 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakespneumatic
 hydraulic
Cab standard with air-conditioning.
Photos
No photos of the SAME Diamond 270 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeload sensing
Valves4
Pump flow31.7 gpm
120.0 lpm
Tractor hitch
Rear lift23149 lbs
10500 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear RPM540E/1000
Engine RPM540E@1630
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front RPM1000
Dimensions & Tires
Wheelbase121.6 inches
308 cm
Weight19951 lbs
9049 kg
Front tire600/65R38
Rear tire710/70R42
Full dimensions and tires ...
References
Diamond 270 references literature
Diamond 230 - 270 published in 2010, by SAME
