Fiat 300M
|
|
| Production | |
| Manufacturer | Fiat |
| Four-wheel Drive (4WD) tractor | |
| Fiat 300M Engine | |
| Fiat 1.6L 2-cyl diesel | |
| Fuel tank | 7.6 gal 28.8 L |
 Engine details ... | |
| Fiat 300M Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Fiat 300M Power | |
| Engine | 28 hp 20.9 kW |
| Mechanical | |
| Drive | 4x4 4WD |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Fiat 300M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2132 psi 147.0 bar |
| Pump flow | 2.6 gpm 9.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Rear lift (at ends) | 1653 lbs 749 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2120 |
| Engine RPM | 994@2250 |
| Dimensions & Tires | |
| Wheelbase | 55.75 inches 141 cm |
| Weight | 2799 lbs 1269 kg |
| Front tire | 8.00-20 |
| Rear tire | 8.00-20 |
 Full dimensions and tires ... | |
| 300M Serial Numbers | |
| Location: | Serial number plate on the left side of the chassis. |
| Belt Pulley | |
| Diameter | 8.2 inches 20 cm |
| Width | 4.7 inches 11 cm |
| RPM | 1431 |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 77 |
| References | |
 | |
| 300 Montagna published in 1971, by Fiat |
