McCormick Intl X1.55
| | 2016 - |
| X1 Series | | Compact Utility tractor | | Kukje built |
|
Series map:
X1.45
X1.55
47.0hp
55.0hp
| Production |
| Distributor | McCormick Intl (a part of Argo)
|
| Manufacturer | Kukje
|
| Compact Utility tractor |
| McCormick Intl X1.55 Power |
| Engine | 55 hp
41.0 kW
|
| PTO (claimed) | 47 hp
35.0 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Cab available with air-conditioning. |
| Photos |
| No photos of the McCormick Intl X1.55 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Rear valves | 2
|
| Mid valves | 2
|
| SCV flow | 11.1 gpm
42.0 lpm
|
| Total flow | 16.8 gpm
63.6 lpm
|
| Steering flow | 5.7 gpm
21.6 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 3306 lbs
1499 kg
|
| Rear lift (at 24"/610mm) | 2425 lbs
1099 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/540E
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| X1.25 published in 2019, by McCormick |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on April 3, 2023 |
