McCormick Intl X1.37
|
|
| Production | |
| Distributor | McCormick Intl (a part of Argo) |
| Manufacturer | Kukje |
| Compact Utility tractor | |
| McCormick Intl X1.37 Engine | |
| Kukje 2.1L 4-cyl diesel | |
| Fuel tank | 12 gal 45.4 L |
 Engine details ... | |
| McCormick Intl X1.37 Transmissions | |
| 12-speed mechanical shuttle | |
| hydrostatic | |
 Transmission details ... |
| McCormick Intl X1.37 Power | |
| Engine | 37 hp 27.6 kW |
| Gear PTO (claimed) | 33 hp 24.6 kW |
| Hydro PTO (claimed) | 32 hp 23.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the McCormick Intl X1.37 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 |
| Mid valves | 2 |
| SCV flow | 10.4 gpm 39.4 lpm |
| Total flow | 15.4 gpm 58.3 lpm |
| Steering flow | 5 gpm 18.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 3306 lbs 1499 kg |
| Rear lift (at 24"/610mm) | 2425 lbs 1099 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E (1.375) |
| Dimensions & Tires | |
| Wheelbase | 71.1 inches 180 cm |
| Weight | 4195 to 4211 pounds |
 Full dimensions and tires ... | |
| McCormick Intl X1.37 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| X1.25 published in 2019, by McCormick |
