TYM 2610
|
|
| Production | |
| Manufacturer | TYM |
| Sub-Compact Utility tractor | |
| The TYM 2610 was also sold as the Branson 2610h before the Branson name was dropped. | |
| TYM 2610 Engine | |
| TYM 1.2L 3-cyl diesel | |
| Fuel tank | 6 gal 22.7 L |
 Engine details ... | |
| TYM 2610 Transmission | |
| hydrostatic | |
 Transmission details ... |
| TYM 2610 Power | |
| Engine (gross) | 24 hp 17.9 kW |
| PTO (claimed) | 18 hp 13.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering |
| Photos | |
| No photos of the TYM 2610 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 2 OptOptional |
| SCV flow | 3.1 gpm 11.7 lpm |
| Total flow | 7.4 gpm 28.0 lpm |
| Steering flow | 4.3 gpm 16.3 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 1499 lbs 679 kg |
| Rear lift (at 24"/610mm) | 974 lbs 441 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Rear RPM | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 65.7 inches 166 cm |
| Weight | 2106 lbs 955 kg |
| Front tire | 6-12 |
| Rear tire | 9.5-16 |
 Full dimensions and tires ... | |
| TYM 2610 attachments | |
| 60" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 60 |
| Battery volts | 12 |
| References | |
 | |
| 10 Series published in 2021, by Branson | |
| 2610 Sub-Compact, Series 1 published in 2023, by TYM |
