Fiat 805C
|
|
| Production | |
| Manufacturer | Fiat |
| Agricultural Crawler tractor | |
| Fiat 805C Engine | |
| Fiat 4.6L 4-cyl diesel | |
| Fuel tank | 21.1 gal 79.9 L |
 Engine details ... | |
| Fiat 805C Transmission | |
| 6-speed crawler | |
 Transmission details ... |
| Fiat 805C Power | |
| Engine | 79.1 hp 59.0 kW |
| Mechanical | |
| Drive | crawler |
| Band brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Fiat 805C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2133 psi (hitch) 147.1 bar |
| 1635 psi (remotes) 112.7 bar | |
| Pump flow | 7.3 gpm (hitch) 27.6 lpm |
| 18.5 gpm (remotes) 70.0 lpm | |
| Tractor hitch | |
| Rear Type | III/II |
| Dimensions & Tracks | |
| Wheelbase | 72 inches 182 cm |
| Weight | 11355 lbs 5150 kg |
| 15.75-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| Battery AH | 143 |
| References | |
 | |
| Operator's Manual 805C (603.04.676) published in 1977 |
