Fiat 955C


Fiat 955C tractor photo
1981 - 1984
55 Series
Agricultural Crawler tractor
Production
ManufacturerFiat
Agricultural Crawler tractor
Fiat 955C Engine
Fiat 4.6L 5-cyl diesel
Fuel tank45 gal
170.3 L
Engine details ...
Fiat 955C Power
Engine88 hp
65.6 kW
Mechanical
Drivecrawler
Final drivesspur gear
Band brakes
Two-post ROPS with canopy.
Photos
No photos of the Fiat 955C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2460 psi
169.6 bar
Rear valves2 to 4
Pump flow11 gpm
41.6 lpm
Tractor hitch
Rear TypeIII/II OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540 (1.375)
Engine RPM540@2227
Dimensions & Tracks
Weight13051 lbs
5919 kg
19.7-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps45
Battery volts12
References
955C references literature
Compect Crawler Tractors 66 & 88 HP published in 1982, by Hesston
