Lamborghini 784
| | 1980 - 1985 |
| Utility tractor |
|
Series map:
754
784
58.2kw
63.4kw
| Production |
| Manufacturer | Lamborghini
|
| Utility tractor |
| Variants |
| 784 | utility tractor
|
| C784 | crawler
|
| Lamborghini 784 Power |
| Engine (gross) | 85 hp
63.4 kW
|
| Engine (net) | 78 hp
58.2 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Four-post ROPS. Cab optional. |
| Photos |
| No photos of the Lamborghini 784 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 8.5 gpm
32.2 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 8378 lbs
3800 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Charging system | alternator
|
| Battery volts | 12
|
| Battery AH | 110
|
| References |
 |
| 784 published in 1981, by Lamborghini |
