Kubota M9570
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Kubota M9570 Engine | |
| Kubota 4.3L 4-cyl diesel | |
| Fuel tank | 31.7 gal 120.0 L |
 Engine details ... | |
| Kubota M9570 Power | |
| Engine | 95 hp 70.8 kW |
| PTO (claimed) | 87 hp 64.9 kW |
| Mechanical | |
| Two- or four-wheel drive |
| Photos | |
| No photos of the Kubota M9570 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 11 gpm 41.6 lpm |
| Tractor hitch | |
| Rear Type | JISII/I |
| Rear lift | 7716 lbs 3499 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540/850/ground (1.375) |
| Engine RPM | 540@2035 |
| 850@2391 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 95.9 inches 243 cm |
| 4WD Wheelbase | 97.2 inches 246 cm |
| Weight | 6878 to 7584 pounds |
| Front tire | 7.50-20 |
| 2WD Rear tire | 16.9-34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual M70 (636830-9971-8) |
