Kubota M7970


No photo available
1984 - 1988
M70 Series
Utility tractor
Series:M6970M7970M9570
Production
Manufacturer:Kubota
Type:Utility tractor
Kubota M7970 Power
Engine:79.5 hp
59.3 kW
PTO (claimed):76 hp
56.7 kW
Kubota M7970 Engine
Kubota 4.3L 4-cyl diesel
Fuel tank:26.4 gal
99.9 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Transmission:16-speed
Transmission details ...
Photos
No photos of the Kubota M7970 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:11 gpm
41.6 lpm
Tractor hitch
Rear Type:JISII/I
Rear lift:5952 lbs
2699 kg
 7716 lbs
3499 kg *Optional
Power Take-off (PTO)
Rear RPM:540/850/ground (1.375)
Engine RPM:540@2035
850@2391
Dimensions & Tires
2WD Wheelbase:87.6 inches
222 cm
4WD Wheelbase:89 inches
226 cm
Weight:5952 to 6614 pounds
Front tire:7.50-16
2WD Rear tire:13.9-36
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
