Valtra S394

No photo available
2017 - 2022
Model year
S Series
Row-Crop tractor
Manufacturer:Valtra (a part of AGCO)
Type:Row-Crop tractor
Valtra S394 Power
Engine:395 hp
294.6 kW
Valtra S394 Engine
AGCO Power 8.4L 6-cyl diesel
Fuel tank:166.4 gal
629.8 L
Exhaust fluid (DEF):15.9 gal
60.2 L
Engine details ...
Chassis:4x4 MFWD 4WD
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning.
Transmission:continuously-variable transmission
Transmission details ...
No photos of the Valtra S394 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Type:closed center load sensing
Rear valves:4 to 6
Front valves:0 to 2
Pump flow:54.2 gpm
205.1 lpm
Tractor hitch
Rear Type:IV/III
Rear lift:26455 lbs
11999 kg
Front lift:11023 lbs
5000 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540E/1000
Engine RPM:540E@1600
Dimensions & Tires
Wheelbase:122.2 inches
310 cm
Weight:22708 lbs
10300 kg
Front tire:620/65R34
Rear tire:710/75R42
Full dimensions and tires ...
Charging system:alternator
Battery volts:12
