Valtra S274


No photo available
2014 - 2025
Model year
S Series
Row-Crop tractor
Series map:
S274
S294
198.4kw
217.0kw
Production
ManufacturerValtra (a part of AGCO)
Row-Crop tractor
Valtra S274 Engine
AGCO Power 8.4L 6-cyl diesel
Fuel tank166.4 gal
629.8 L
Exhaust fluid (DEF)15.9 gal
60.2 L
Engine details ...
Valtra S274 Transmission
continuously-variable transmission
Transmission details ...
Valtra S274 Power
Engine266 hp
198.4 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Valtra S274 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load sensing
Rear valves4 to 6
Front valves0 to 2
Pump flow54.2 gpm
205.1 lpm
Tractor hitch
Rear TypeIV/III
Rear lift26455 lbs
11999 kg
Front lift11023 lbs
5000 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540E/1000
 1000E/1000
Engine RPM540E@1600
 1000E@1600
 1000@2030
Dimensions & Tires
Wheelbase122.2 inches
310 cm
Weight22708 lbs
10300 kg
Front tire600/70R28
Rear tire650/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
S274 references literature
S Series published in 2014, by Valtra
S Series published in 2017, by Valtra
