Valtra S263


Valtra S263 tractor photo
2011 - 2013
S Series
Row-Crop tractor
Series map:
S233
S263
S293
198.4kw
217.0kw
235.6kw
Production
ManufacturerValtra (a part of AGCO)
Row-Crop tractor
Valtra S263 Engine
SisuDiesel 8.4L 6-cyl diesel
Fuel tank161.1 gal
609.8 L
Exhaust fluid (DEF)15.9 gal
60.2 L
Engine details ...
Valtra S263 Transmission
continuously-variable transmission
Transmission details ...
Valtra S263 Power
Engine291 hp
217.0 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Valtra S263 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load sensing
Rear valves4 to 6
Front valves0 to 2
Pump flow52.8 gpm
199.8 lpm
Tractor hitch
Rear TypeIV/III
Rear lift26455 lbs
11999 kg
Front lift11023 lbs
5000 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000/1000E (1.375)
Engine RPM1000E@1600
 1000@2031
Dimensions & Tires
Wheelbase122.2 inches
310 cm
Weight22708 lbs
10300 kg
Front tire600/70R28
Rear tire650/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
S263 references literature
S Series published in 2013, by Valtra
