Production | |
Manufacturer: | Fendt (a part of AGCO) |
Type: | Row-Crop tractor |
Fendt 936 Vario Power | |
Engine (gross): | 356 hp 265.5 kW |
Engine (net): | 330 hp 246.1 kW |
Engine (max): | 366 hp 272.9 kW |
Fendt 936 Vario Engine | |
Deutz 7.8L 6-cyl diesel | |
Fuel tank: | 158.5 gal 599.9 L |
Exhaust fluid (DEF): | 15.9 gal 60.2 L |
Engine details ... |
Mechanical | |
Chassis: | 4x4 MFWD 4WD |
Steering: | power |
Brakes: | hydraulic wet disc |
Cab: | Cab standard with air-conditioning. |
Transmission: | continuously-variable transmission |
Transmission details ... |
Photos | |
No photos of the Fendt 936 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
Valves: | 4 to 8 |
Pump flow: | 42.3 gpm 160.1 lpm |
57.1 gpm 216.1 lpm *Optional |
Tractor hitch | |
Rear lift: | 26526 lbs 12032 kg |
Front lift: | 12476 lbs 5659 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Rear RPM: | 540E/1000 |
1000/1000E | |
Front PTO: | independent*Optional |
Front RPM: | 1000 |
Dimensions & Tires | |
Wheelbase: | 120.1 inches 305 cm |
Weight: | 23876 lbs 10830 kg |
Front tire: | 600/70R34 |
Rear tire: | 710/75R42 |
Full dimensions and tires ... |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Charging amps: | 300*Dual 150A alternators. |
Battery volts: | 12 |
