Fendt 933 Vario
| | 2006 - 2022 |
|
| 900 Vario Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Fendt (a part of AGCO)
|
| Type: | Row-Crop tractor
|
| Fendt 933 Vario Power |
| Engine (gross): | 324 hp
241.6 kW
|
| Engine (net): | 300 hp
223.7 kW
|
| Engine (max): | 333 hp
248.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | continuously-variable transmission
|
 Transmission details ... |
| Photos |
| No photos of the Fendt 933 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves: | 4 to 8
|
| Pump flow: | 42.3 gpm
160.1 lpm
|
| | 57.1 gpm
216.1 lpm *Optional
|
| Tractor hitch |
| Rear lift: | 26526 lbs
12032 kg
|
| Front lift: | 12476 lbs
5659 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540E/1000
|
| | 1000/1000E
|
| Front PTO: | independent*Optional
|
| Front RPM: | 1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 300*Dual 150A alternators.
|
| Battery volts: | 12
|
