Fiat 446
|
|
| Production | |
| Manufacturer | Fiat |
| Utility tractor | |
| Variants | |
| 446DT | 4WD |
| Fiat 446 Engine | |
| Fiat 2.6L 3-cyl diesel | |
| Fuel tank | 16.1 gal 60.9 L |
 Engine details ... | |
| Fiat 446 Transmissions | |
| 8-speed gear | |
| 12-speed gear | |
 Transmission details ... |
| Fiat 446 Power | |
| Engine | 50 hp 37.3 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | planetary |
| Differential lock | mechanical rear |
| Steering | manual |
| Steering | power OptOptional |
| Drum brakes | |
| Four-post ROPS. | |
| Photos | |
| No photos of the Fiat 446 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2160 |
| Dimensions & Tires | |
| 2WD Wheelbase | 80.7 inches 204 cm |
| 4WD Wheelbase | 79.2 inches 201 cm |
| Weight | 4299 to 4762 pounds |
| Front tire | 6.00-16 |
| 2WD Rear tire | 12.4/11-32 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 33 |
| Battery volts | 12 |
| References | |
 | |
| Workshop Manual 446 - 446 DT published in 1985 |
