Tractors > John Deere > 6410SE

John Deere 6410SE



John Deere 6410SE tractor photo
1998 - 2003
6010SE Series
Utility tractor
Series map:
6310SE
6410SE
74.6kw
78.3kw
Production
ManufacturerJohn Deere
Utility tractor
John Deere 6410SE Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 6410SE Transmissions
12-speed synchronized
16-speed power shuttle
16-speed four-speed power shift
Transmission details ...
John Deere 6410SE Power
Engine (net)105 hp
78.3 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with heat. Optional air-conditioning.
Photos
No photos of the John Deere 6410SE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel43.6 gal
165.0 L
 30.6 gal (LP Cab)
115.8 L
Hydraulic system14.5 gal
54.9 L
Hydraulics
Typeopen center load-sensing
Capacity14.5 gal
54.9 L
Pressure2901 psi
200.0 bar
Valves4 OptOptional
Pump flow14.3 gpm
54.1 lpm
Tractor hitch
Rear TypeII
Controlelectronic lower-link draft sensing
Rear lift11825 lbs
5363 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@2124
 1000@2208
 540E@1684
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@2185
Dimensions & Tires
Wheelbase94.5 inches
240 cm
Weight8990 lbs
4077 kg
Front tire13.6R24
Rear tire16.9R34
Full dimensions and tires ...
6410SE Serial Numbers
Location:Serial number plate on the right side of the tractor's frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery volts12
Battery AH110
References
6410SE references literature
New 6010 SE Series Tractors published in 1998, by John Deere
6010 SE Series Tractors published in 2002, by John Deere
