John Deere 6310SE

No photo available
1998 - 2003
6010SE Series
Utility tractor
Manufacturer:John Deere
Type:Utility tractor
John Deere 6310SE Power
Engine (net):100 hp
74.6 kW
John Deere 6310SE Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:electro-hydraulic rear
Brakes:hydraulic wet disc
Trailer brakes:hydraulic*Optional
Cab:Cab standard with heat. Optional air-conditioning.
Transmissions:12-speed synchronized
 16-speed power shuttle
 16-speed four-speed power shift
Transmission details ...
No photos of the John Deere 6310SE are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Fuel:43.6 gal
165.0 L
 30.6 gal
115.8 L (LP Cab)
Hydraulic system:14.5 gal
54.9 L
Type:load sensing
Capacity:14.5 gal
54.9 L
Pressure:2901 psi
200.0 bar
Pump flow:14.3 gpm
54.1 lpm
Tractor hitch
Rear Type:II
Control:electronic lower-link draft sensing
Rear lift:10319 lbs
4680 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540
Engine RPM:540@2124
Front PTO:independent
Clutch:electro-hydraulic wet disc
Front RPM:1000
Engine RPM:1000@2185
Dimensions & Tires
Wheelbase:94.5 inches
240 cm
Weight:8924 lbs
4047 kg
Front tire:13.6R24
Rear tire:16.9R34
Full dimensions and tires ...
6310SE Serial Numbers
Location:Serial number plate on the right side of the tractor’s frame.
Charging system:alternator
Charging amps:90
Battery volts:12
Battery AH:110
