TYM T1104
|
|
| Production | |
| Manufacturer | TYM |
| Utility tractor | |
| TYM T1104 Engine | |
| Doosan 3.4L 4-cyl diesel | |
| Fuel tank | 29.1 gal 110.1 L |
| Exhaust fluid (DEF) | 5.3 gal 20.1 L |
 Engine details ... | |
| TYM T1104 Transmission | |
| 32-speed power shuttle | |
 Transmission details ... |
| TYM T1104 Power | |
| Engine (gross) | 105 hp 78.3 kW |
| PTO (claimed) | 95.5 hp 71.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
 | |
 TYM T1104 photos... | |
| Hydraulics | |
| Type | open center |
| Pump flow | 14.1 gpm 53.4 lpm |
| Total flow | 21.3 gpm 80.6 lpm |
| Steering flow | 7.1 gpm 26.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 6860 lbs 3111 kg |
| Rear lift (at 24"/610mm) | 5490 lbs 2490 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 90.6 inches 230 cm |
| Weight | 8666 lbs 3930 kg |
| Front tire | 380/85R24 |
| Rear tire | 460/85R34 |
 Full dimensions and tires ... | |
| TYM T1104 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 110 |
| Battery volts | 12 |
| References | |
 | |
| T1104 Utility, Series 6 published in 2025, by TYM |
