Tractors > CaseIH > CS 150

CaseIH CS 150



CaseIH CS 150 tractor photo
1997 - 2003
CS Series
Row-Crop tractor
Series map:
CS 130
CS 150
91.9kw
106.6kw
Production
ManufacturerCaseIH
Row-Crop tractor
Built in Saint Valentin, Austria
Variants
9145similar Steyr model
CaseIH CS 150 Engine
Sisu 6.6L 6-cyl diesel
Fuel tank58.1 gal
219.9 L
 79.3 gal*Total capacity with optional 80 liter fuel tank.
300.2 L
Engine details ...
CaseIH CS 150 Transmissions
24-speed four-speed power shift
40-speed creeper
Transmission details ...
CaseIH CS 150 Power
Engine (net)143 hp
106.6 kW
PTO (claimed)129.2 hp
96.3 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the CaseIH CS 150 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2683 psi
185.0 bar
Pump flow21.1 gpm
79.9 lpm
 30.4 gpmOptOptional
115.1 lpm
Tractor hitch
Rear TypeIII
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@2200
 540E@1680
 1000@2200
 1000E@1600
Front PTO Type1000
Dimensions & Tires
Wheelbase110.6 inches
280 cm
Weight11651 lbs
5284 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
References
CS 150 references literature
CS110-CS150 published in 1998, by CaseIH
CS110 & CS150 published in 2000, by CaseIH
