Renault 70-14 LB


Renault 70-14 LB tractor photo
1987 - 1998
LB Series
Utility tractor
Series:70-12 LB70-14 LB
Production
Manufacturer:Renault
Type:Utility tractor
Variants
70-12 LB:2WD
Renault 70-14 LB Power
Engine:65.7 hp
49.0 kW
Renault 70-14 LB Engine
Deutz 3.8L 4-cyl diesel
Fuel tank:16.4 gal
62.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:planetary
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Four-post ROPS. Cab optional.
Transmission:12-speed Four gears in three ranges with mechanical shuttle.
Transmission details ...
Photos
No photos of the Renault 70-14 LB are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2611 psi
180.0 bar
Valves:1
Pump flow:9.6 gpm
36.3 lpm
Tractor hitch
Rear Type:II
Control:position and draft control
Rear lift:7666 lbs
3477 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Weight:5622 lbs
2550 kg
Front tire:12.4-20
Rear tire:16.9-28
Full dimensions and tires ...
