Renault 70-14 LB
| | 1987 - 1998 |
| LB Series | | Utility tractor | | Carraro built |
|
Series map:
70-12 LB
70-14 LB
49.0kw
49.0kw
| Production |
| Distributor | Renault
|
| Manufacturer | Carraro
|
| Utility tractor |
| Built in Italy |
| Renault 70-14 LB Power |
| Engine | 65.7 hp
49.0 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Four-post ROPS. Cab optional. |
| Photos |
| No photos of the Renault 70-14 LB are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2611 psi
180.0 bar
|
| Valves | 1
|
| Pump flow | 9.6 gpm
36.3 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 7666 lbs
3477 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| References |
 |
| Baureihe LB published in 1992, by Renault |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on October 27, 2025 |
